Description
Lifecycle
- Obsolete Date 31-10-2022
- End of support date 31-10-2027
Specifications
- Warranty The warranty for this device is 3-years parts only.
- Servers supported HPE ProLiant DL360 Gen10 HPE ProLiant DL560 Gen10
- RAID levels 0, 1, 5, 10
- Additional features HPE Smart Array SR Secure Encryption (optional license)
- Ports Internal: 8 SAS lanes across 2 x4 Mini-SAS ports
- Cache No cache
- Transfer rate 12Gb/s SAS per lane 6Gb/s SATA per lane PCI Express 3.0 x8 lane width
- Form factor Type-a modular controller
Quickspecs
Overview
Are you looking for a cost effective, enterprise-class controller for internal attached drives without occupying a PCIe expansion slot? The HPE Smart Array E208i-a SR Gen10 Controller, supporting 12 Gb/s SAS and PCIe 3.0, provides a cost-effective storage solution with enterprise-class reliability supporting RAID 0, 1, 5, and 10 and software-defined storage (SDS). This controller has eight internal SAS lanes, allowing connection to SAS or SATA drives, supports Mixed Mode operations of RAID and HBA simultaneously, and offers encryption for data-at rest on any drive. This type-a modular controller occupies a dedicated storage slot without occupying a PCIe expansion slot.
Features
Cost-Effective SAS Storage Connectivity
The HPE Smart Array E208i-a SR Gen10 Controller is a cost effective enterprise-class controller that provides the basic building blocks for simple RAID storage solutions while delivering 12 Gb/s SAS connectivity on HPE ProLiant Gen10 Servers when connected to 12 Gb/s internal storage devices.
Offers a low-cost solution to enable software-defined storage.
Rapidly configure simple RAID volumes on servers with the UEFI storage configuration tool, which also facilitates scripting support to configure an array via iLO through RESTful interface.
The HPE Smart Array E208i-a SR Gen10 Controller has increased flexibility with Mixed Mode which operates in RAID and HBA simultaneously and eliminates the expense of having to purchase another controller.
Improved Efficiency and Storage Management
Preserve data integrity with HPE SmartSSD Wear Gauge, which alerts you to potential drive issues before a drive fails.
Comply with regulations for sensitive data, such as HIPAA and Sarbanes-Oxley with HPE Smart Array SR Secure Encryption.
The HPE Smart Array E208i-a SR Gen10 Controller protects data-at-rest on any drive attached to the controller with HPE Smart Array SR Secure Encryption (optional license).
Built-in Reliability and Security
Quickly set up, configure, and manage drives attached to the controller with HPE Smart Storage Administrator (SSA), an intuitive interface used to create RAID volumes, manage advanced controller features, and deploy Smart Array solutions.
Compatible products
- HPE 12W Smart Storage Battery
- HPE DL560 Gen10 5120 2P32GB Ent WW Svr
- HPE DL360 Gen10 3106 1P 16G 8SFF Svr
- HPE ProLiant DL360 Gen10 4114 85W 1P 16G-2R P408i-a 8SFF 1x500W Base Server
- HPE DL360 Gen10 5118 2P 32G 8SFF Svr
- HPE ProLiant DL360 Gen10 6130 125W 2P 64G-2R P408i-a Premium 10NVMe 2x800W High Perf Svr
- HPE ProLiant DL560 Gen10 6130 2P 64GB-R P408i-a 8SFF 2x1600W PS Entry Server
- HPE ProLiant DL360 Gen10 Intel Xeon-S 4110 8-Core (2.10GHz 11MB) 16GB (1 x 16GB) PC4-2666V-R DDR4 2666MHz RDIMM 2 x 300GB (15k rpm) Hot Plug 2.5in Small Form Factor Smart Carrier SAS Smart Array P408i-a SR 500W 3yr Next Business Day Warranty
- HPE ProLiant DL360 Gen10 Intel Xeon-S 4114 10-Core (2.20GHz 13.75MB) 32GB (1 x 32GB) PC4-2666V-R DDR4 2666MHz RDIMM 2 x 300GB (15k rpm) Hot Plug 2.5in Small Form Factor Smart Carrier SAS Smart Array P408i-a SR No Optical 2 x 500W 3yr Next Business Day Warranty
- HPE ProLiant DL160 Gen10 3106 1P 16GB-R S100i 4LFF 1x500W PS Server
- HPE ProLiant DL160 Gen10 4110 1P 16GB-R S100i 8SFF 1x500W PS Server
- HPE ProLiant DL360 Gen10 6130 125W 2P 64G-2R P408i-a Premium 10NVMe 2x800W High Perf Svr
- HPE 12W Smart Storage Battery (up to 3 Devices) for BladeSystem Server
- HPE 12W Smart Storage Battery (up to 3 Devices) for Apollo XL230k Gen10 Server
- HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit
- HPE 96W Smart Storage Lithium-ion Battery with 260mm Cable Kit
- HPE DL360 Gen10 3104 1P 8GB 4LFF WW Svr
- HPE Smart Storage Hybrid Capacitor with 145mm Cable Kit
- HPE Smart Storage Hybrid Capacitor with 260mm Cable Kit
- HPE ProLiant DL360 Gen10 5220 2P 64GB-R P408i-a 8SFF 800W RPS Server
- HPE ProLiant DL360 Gen10 6248 2P 64GB-R P408i-a 8SFF 800W RPS Server
- HPE ProLiant DL560 Gen10 5220 2P 64GB-R P408i-a 8SFF 2x1600W RPS Server
- HPE ProLiant DL560 Gen10 6230 2P 128GB-R P408i-a 8SFF 2x1600W RPS Server
- HPE ProLiant DL360 Gen10 3204 1P 16GB-R S100i 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 4208 1P 16GB-R P408i-a 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 4210 1P 16GB-R P408i-a 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 4214 1P 16GB-R P408i-a 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 5218 1P 32GB-R P408i-a 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 6230 1P 32GB-R P408i-a 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 4208 1P 16GB-R S100i 4LFF 500W PS Server
- HPE ProLiant DL325 Gen10 7251 1P 8GB-R E208i-a 4LFF 500W PS Entry Server
- HPE ProLiant DL325 Gen10 7351P 1P 16GB-R E208i-a 8SFF 1x500W PS Performance Server
- HPE ProLiant DL325 Gen10 7401P 1P 32GB-R P408i-a 8SFF 1x800W PS Performance Server
- HPE ProLiant DL325 Gen10 7251 1P 16GB-R P408i-a 8SFF 2x500W PS Solution Server
- HPE ProLiant DL325 Gen10 7351P 1P 16GB-R P408i-a 8SFF 500W RPS Performance Server
- HPE ProLiant DL360 Gen10 4110 1P 16GB-R P408i-a 8SFF 500W RPS Solution Server
- HPE ProLiant DL360 Gen10 4110 1P 16GB-R P408i-a 8SFF 500W PS Performance Server
- HPE ProLiant DL360 Gen10 5118 1P 32GB-R P408i-a 8SFF 800W RPS Performance Server
- HPE ProLiant DL360 Gen10 6130 1P 64GB-R P408i-a 8SFF 800W RPS Performance Server
- HPE ProLiant DL20 Gen10 G5400 1P 8GB-U 2LFF NHP 290W PS Entry Server
- HPE ProLiant DL20 Gen10 E-2124 1P 16GB-U 2LFF 290W PS Perf Server
- HPE ProLiant DL20 Gen10 E-2136 1P 16GB-U 4SFF 500W PS Perf Server
- HPE ProLiant DL20 Gen10 E-2134 1P 16GB-U 4SFF 500W PS Solution Server
- HPE ProLiant DL20 Gen10 E-2124 1P 8GB-U 2LFF NHP 290W PS Entry Server
- HPE ProLiant DL325 Gen10 7402P 1P 64GB-R P408i-a 8SFF 800W RPS Server
- HPE ProLiant DL20 Gen10 E-2224 1P 16GB-U S100i 4SFF 500W RPS Server
- HPE ProLiant DL325 Gen10 7262 1P 16GB-R S100i 4LFF 800W RPS Server
- HPE ProLiant DL325 Gen10 7262 1P 16GB-R P408i-a 8SFF 500W RPS Server
- HPE ProLiant DL325 Gen10 7302P 1P 16GB-R P408i-a 8SFF 800W RPS Server
- HPE ProLiant DL360 Gen10 5217 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 5220 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 5222 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 6234 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 6242 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL160 Gen10 4208 1P 16GB-R 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 5220 2P 64GB-R P408i-a NC 8SFF 800W RPS Server
- HPE ProLiant DL360 Gen10 6248 2P 64GB-R P408i-a NC 8SFF 800W RPS Server
- HPE ProLiant DL360 Gen10 4208 1P 16GB-R P408i-a NC 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 4214 1P 16GB-R P408i-a NC 8SFF 500W PS Server
- HPE ProLiant DL360 Gen10 4208 1P 16GB-R S100i NC 4LFF 500W PS Server
- HPE ProLiant DL360 Gen10 5218 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 6230 1P 32GB-R P408i-a NC 8SFF 800W PS Server
- HPE ProLiant DL360 Gen10 4210 1P 16GB-R P408i-a NC 8SFF 500W PS Server
