Description
Placa de baza Gigabyte X570S GAMING X AM4 CPU: AMD Socket AM4, support for: AMD Ryzenâ„¢ 5000 Series/ Ryzenâ„¢ 5000 G-Series/ AMD Ryzenâ„¢ 4000 G- Series/ AMD Ryzenâ„¢ 3000 Series/ AMD Ryzenâ„¢ 3000 G-Series/ AMD Ryzenâ„¢ 2000 Series/ AMD Ryzenâ„¢ 2000 G-Series Processors (Please refer “CPU Support List” for more information. ) Chipset: AMD X570 Memory: 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture Support for DDR4 5100(O. C. ) / 4800(O. C. ) / 4600(O. C. ) / 4400(O. C. ) / 4266(O. C. ) / 4133(O. C. ) / 4000(O. C. ) / 3866(O. C. ) / 3733(O. C. ) / 3600(O. C. ) / 3466(O. C) / 3400(O. C. ) / 3200(O. C. ) / 2933 / 2667 / 2400 / 2133 MHz memory modules Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules* * ECC memory (ECC mode) support varies by CPU Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer “Memory Support List” for more information. ) Onboard Graphics: Integrated Graphics Processor: 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio: Realtek® Audio CODEC High Definition Audio 2/4/ 5.1 / 7.1 – channel LAN: Realtek® 2.5G bE LAN chip ( 2.5 Gbps/1 Gbps/100 Mbps) Expansion Slots: 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzenâ„¢ 5000 Series Processors/AMD Ryzenâ„¢ 3000 Series Processors support PCIe 4.0 x16 mode AMD Ryzenâ„¢ 4000 G-Series Processors/AMD Ryzenâ„¢ 2000 Series Processors support PCIe 3.0 x16 mode AMD Ryzenâ„¢ 3000 G- Series Processors/AMD Ryzenâ„¢ 2000 G-Series Processors support PCIe 3.0 x8 mode * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset: Supporting PCIe 4.0 (Note) / 3.0 x2 mode * The PCIEX2 slot shares bandwidth with the SATA3 4, 5 connectors. The SATA3 4, 5 connectors will become unavailable when a device is installed in the PCIEX2 slot. 2 x PCI Express x1 slots, integrated in the Chipset, supporting PCIe 4.0 (Note) / 3.0 (Note) For AMD Ryzenâ„¢ 5000 Series Processors/AMD Ryzenâ„¢ 3000 Series Processors only. Storage Interface: 1 x M. 2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: AMD Ryzenâ„¢ 5000 Series Processors/AMD Ryzenâ„¢ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs AMD Ryzenâ„¢ 4000 G-Series Processors/AMD Ryzenâ„¢ 3000 G-Series Processors/AMD Ryzenâ„¢ 2000 Series Processors/AMD Ryzenâ„¢ 2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M. 2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: Supporting PCIe 4.0 (Note) / 3.0 x4/x2 SSDs 1 x M. 2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: Supporting SATA and PCIe 4.0 (Note) / 3.0 x4/x2 SSDs 6 x SATA 6Gb/s connectors, integrated in the Chipset: Support for RAID 0, RAID 1, and RAID 10 (Note) For AMD Ryzenâ„¢ 5000 Series Processors/AMD Ryzenâ„¢ 3000 Series Processors only. USB: CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB Type-C® ports, with USB 3.2 Gen 2 support (1 port on the back panel, 1 port available through the internal USB header) 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0 / 1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) Internal I/O Connectors: 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 1 x CPU co
Additional information
| Form factor | |
|---|---|
| Socket CPU | |
| PCI | |
| Slot PCI-Ex1 | |
| Slot PCI-Ex16 | |
| Slot RAM | |
| Serial-or-Paralel | |
| USB | |
| Onboard-CPU | |
| Producator | |
| Garantie |
